示教编码:在设置过程中,执行器通过示教进行编程,并永久地分配给传感器(必要时可以重复该过程)
安全水平 | PL e |
安全输入 | 2个数字输入 |
安全等级(SIL / PL) | SIL 3 - SILCL 3 - PL e - Cat. 4 |
工作温度 (°C) | -25到70 |
响应时间 (ms) | 55 |
传感器类型 | 下一代RFID安全传感器 |
安全输出型 | 2 PNP ( 300 mA, 24 VDC下),自控制,带短路、过载 |
材料适用于食品应用 | 是 |
最小开关电流(24 VDC时)(mA) | 300 |
安全输出数量 | 2 对OSSD (300 mA) |
测试输出 | 1 |
LED信号指示 | 3 色 LED 状态信号 |
编码类型 | 带示教编码的执行器 |
产品分类 | A |
海关代码 | 9032890 |
连接类型 | 带电缆 |
电源 (VDC) | 24 ± 20% |
连接器 | M12 8 极公头 |
尺寸HxWxD (mm) | 28,5 x 50 x 18 |
防护等级 | IP67 |
紧固方法 | M4螺钉(如M4 x 20)。 |
外壳 | Nylon / 矩形 |
开关距离 (mm) | 12 … 25 |
尺寸 | 22 mm interaxis |
